Architectural · A-5F8S6

Accessibility Mounting Heights for Electrical Controls and Fire Alarm Devices

Elements

About this detail

Fire alarm pull stations, light switches, wall dimmers, thermostats, and other electrical controls are mounted at a maximum height of 4 feet 0 inches above the finished floor. Fire alarm audio-visual devices and visual strobes are positioned at a height of 6 feet 8 inches, with audio-visual units vertically aligned with the controls below where they occur in the same wall space.
