Architectural · A-5EZDG

Atrium Stair - Entry Flight South Elevation

Scale: 1/2" = 1'-0"
Units: imperial
Sheet: A5.11
Discipline: Architectural

Elements

Entrances Stairs

Text on the drawing

2ND FL. 440' - 7 3/4" 8 A5.11 2' - 6" 3' - 8" 4' - 0" F4
