A coping stone termination at a parapet wall with reinforced waterproofing membrane. A coping stone is installed per manufacturer specifications over the wall assembly. Water cut-off mastic is applied at the joint beneath the stone, and bonding adhesive secures the reinforced membrane along the vertical face. Bonding adhesive is not required when the flashing height is eighteen inches or less.
BONDING ADHESIVE IS NOT REQUIRED WHEN FLASHING HEIGHT IS 18" OR LESS COPING STONE INSTALL PER MANUFACTURER REINFORCED MEMBRANE WATER CUT-OFF MASTIC BONDING ADHESIVE COPING STONE TERMINATION
