An inside corner assembly of a curtain wall system features aluminum curtain wall mullions meeting at an angle with adjoining glazing units. Exterior aluminum horizontal and vertical fins attach to the mullions for solar shading and aesthetic articulation. Dimensions indicate varying offsets and equal spacing configurations across the corner profile.
4" 6 1/2" 1 3/8" 1' - 4" 3 1/4" EQ EQ 1 3/4" GLAZING UNIT ALUM HORIZONTAL FIN ALUM CURTAIN WALL MULLION ALUM VERTICAL FIN ALUM HORIZONTAL FIN 4" 4" GLAZING UNIT ALUM HORIZONTAL FIN ALUM CURTAIN WALL MULLION ALUM VERTICAL FIN ALUM HORIZONTAL FIN 4" 4" 4 1/2" 4 1/2" 6 1/2" 1 1/4" 1 3/4" 1 3/4" 3 3/8" 3 3/8" 1 3/8" 6 1/2" 4" 4" 1' - 4" 1' - 4" 4" 4" VARIES VARIES 7
