This interior partition detail shows a metal stud framing cavity filled with batt insulation and faced on both sides with gypsum board layers. An overall width dimension spans across the bottom of the wall assembly. Horizontal channel framing runs through the core of the stud cavity.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
