The screen structure mounts outboard of the primary steel roof beam. The primary structure is defined per structural drawings; the screen structure is provided for design intent only and is subject to separate delegated structural design. A three-inch clearance is maintained between the top of the screen assembly and the roof deck above. The screen support is positioned five and one-half inches from the face of the primary structural member, with a total offset of one foot eight and seven-eighths inches to the center of the primary beam. The top of the steel for the upper roof is established at elevation 96.83 feet.
