An exterior insulation finish system is applied over a framed wall at a building corner. A steel tube column is positioned on the interior side of the assembly. An exterior screen wall intersects the framed wall perpendicularly, with a detail reference marker pointing to the junction.
INTERIOR EXTERIOR AH12.2 15 SIM. EXTERIOR INSULATION FINISH SYSTEM OVER FRAMED WALL SCREEN WALL STEEL TUBE
