Linear wood ceiling panels feature an abutting edge configuration with a one-half inch reveal between panels. Each wood panel secures directly to a wood backer above. A metal suspension system, designated as MSS-2, attaches to the wood backer and suspends from the overhead structure.
DIM PT METAL SUSPENSION SYSTEM, MSS-2; DIRECT ATTACH TO WOOD CEILING BACKER WOOD BACKER LINEAR WOOD CEILING SYSTEM A T A B U T T I N G P A N E L S 1 / 2 " R E V E A L METAL SUSPENSION SYSTEM, ATTACH TO STRUCTURE
