An aluminum window system is installed within a concrete tilt-up panel assembly, sized per the window schedule. Dark bronze break metal flashing attaches to the exterior using polyurethane construction adhesive, with seams provided as required. The break metal terminates beneath the window frame, and corners are sealed with compatible sealant.
ALUMINUM WINDOW SYSTEM - SEE WINDOW SCHEDULE TERMINATE BREAK METAL UNDER FRAME - CAULK CORNERS WITH COMPATIBLE SEALANT BREAK METAL - DARK BRONZE ATTACH W/ POLYURETHANE CONSTRUCTION ADHESIVE BREAK METAL SEAM - AS REQUIRED 2" 2" 2" ALUMINUM WINDOW SYSTEM - SEE WINDOW SCHEDULE CONCRETE TILT-UP PANEL EXTERIOR INTERIOR 4'-0"
