A steel column bears on a one-and-a-half-inch non-shrink grout layer atop a concrete slab on grade. The column is secured by a half-inch steel base plate anchored using four five-eighths-inch diameter by six-inch Titen HD concrete screws. Typical steel studs and a continuous bottom track frame adjacent to the column base.
STEEL COLUMN TYPICAL STUDS CONT. BOTTOM TRACK 1/2" STEEL BASE PL W/(4) 5/8" DIA X 6" TITEN HD TO SLAB ON 1 1/2" NON-SHRINK GROUT CONCRETE SLAB ON GRADE B B @ STEEL COLUMN SECTION B-B LEVEL 01 100' - 0"
