Three 305x457x914 lockers sit on a locker base adjacent to filing cabinets not in contract below the underside of the second floor slab and an adjacent stair beyond. Grid lines X, GB, and M21 coordinate the millwork position.
RF3 GB X M21 U/S OF 2ND FLOOR SLAB FILING CABINET (N.I.C) BB OPEN BEYOND LOCKER BASE 3 - 305x457x914 LOCKERS STAIR BEYOND 914 x 914
