A concrete-filled CMU wall supports an adhered manufactured stone veneer set in a mortar setting bed over a mortar scratch coat and lath. A fluid applied air and water barrier coats the exterior face of the CMU wall behind the lath. The top of the wall features a level scratch coat finished with an adhered manufactured stone veneer cap in a mortar setting bed.
MORTAR JOINT (IF REQ.) ADHERED MANUFACTURED STONE VENEER MORTAR SETTING BED MORTAR SCRATCH COAT LATH CONCRETE FILLED CMU WALL, RE: STRUCT. DWGS FLUID APPLIED AIR / WATER BARRIER ADHERED MANUFACTURED STONE VENEER CAP IN MORTAR SETTING BED 1" MIN. LEVEL SCRATCH COAT AT TOP OF WALL
