A Greenheck FSD-211 1-1/2 hour UL555 rated smoke damper is installed within a partition wall located between a stair and an elevator shaft. A steel beam supports the assembly, with framing sizes coordinated per structural drawings. Partition types are referenced to the floor plan.
GREENHECK FSD-211 1-1/2 HOUR, UL555 RATED EQ EQ STEEL BEAM, SEE STRUCTURAL DRAWINGS SEE FLOOR PLAN FOR PARTITION TYPE ELEVATOR SHAFT STAIR SCALE: 1 1/2" = 1'-0" 5 SMOKE DAMPER AT MECH. SHAFT
