Panel edge geometry and tangent points centered on a structural steel column. The layout includes a six-inch radius curve, a thirty-five degree angle, and specific dimensional callouts for the panel edge and tangent line.
CENTER OPENING ON COLUMN STEEL COLUMN 3 1 / 2 " 1 0 1 / 4 " 3 1 / 2 " 1 ' - 1 7 / 8 " 1 1 / 8 " 7 1 / 4 " 1 1 / 8 " 3 " R 6 " R 6 " 3 5 . 0 0 ° TANGENT POINTS TANGENT POINTS TANGENT LINE PANEL EDGE
