Scheduled carpet is installed over a crack suppression membrane and feathered cement fill with a maximum one percent slope on a concrete floor. Scheduled floor tile is set in thin-set mortar over a crack suppression membrane on the adjacent concrete floor. An aluminum transition strip joins the carpet and tile finishes, aligning with the centerline of the door or opening where applicable.
CENTERLINE OF TRANSITION TO ALIGN WITH CENTERLINE OF DOOR OR OPENING, WHERE OCCURS UNDERCUT AS REQUIRED TO CLEAR TRANSITION SCHEDULED FLOOR TILE FEATHER CEMENTI FILL TO 1% SLOPE MAX. CONCRETE FLOOR THIN SET SCHEDULED CARPET CRACK SUPRESION MEMBRANE SCHEDULED ALUMINUM TRANSITION STRIP ALIGN
