A concrete tilt-up panel bears above an exterior concrete apron with a one-half-inch expansion joint located at the exterior concrete apron per the site plan. A steel door jamb extends two inches minimum into the concrete, featuring a sloped transition. The finished floor elevation sits above the concrete apron with indicated panel thickness and dimensions.
