An aluminum expansion joint cover spans across structural steel framing per the structural drawings. Prefinished booth liner ceiling panels connect to the assembly with attachment methods specified by the booth manufacturer. Hole placement for panel attachment requires coordination with the booth manufacturer steel framing. Sheet metal flashing, painted to match the ceiling panel, finishes the joint assembly.
PREFINISHED BOOTH LINER CEILING PANEL BY BOOTH MFR ATTACHMENT PER BOOTH MFR, COORDINATE BOOTH PANEL ATTACHMENT HOLE PLACEMENT WITH BOOTH MFR STEEL FRAMING, REFER TO STRUCTURAL SHEET METAL FLASHING BY BOOTH MFR; PAINTED TO MATCH CEILING PANEL
