A steel stair assembly features metal pan treads or concrete-filled steel pan treads supported by a metal plate or channel stringer. The guardrail incorporates a one and one-half inch diameter outside diameter tube and a one and one-half inch diameter pipe rail, engineered to prevent the passage of four-inch and three-and-three-quarter-inch spheres. The stair connection is secured using a bolted steel angle anchored to the structural support below.
1 1/2" DIA. O.D. TUBE 1 1/2" DIA. PIPE RAIL METAL PLATE OR CHANNEL STRINGER MIN. 1'-0" 3'-6" 3'-0" 1 1/2" METAL PAN STEEL TREADS OR CONC. FILLED STEEL PAN TREADS BOLT STAIR CONNECTION W/ STEEL ANGLE 4" 3 3/4" DIA. SPHERE SHALL NOT PASS THROUGH 4 3/8" DIA. SPHERE SHALL NOT PASS THROUGH 4 3 7/8"
