Roof panel returns and ledger splices meet at high or low building points. Elevation A contains an angle ledger per the roof plan connected via one hundred percent welded joints, with additional information referenced on sheet SD.4. Elevation B contains a channel ledger per the roof plan featuring similar welded splice conditions. Panel elevations and remaining connection details are coordinated with the corresponding structural sheets.
