Electrical and data/telephone boxes are installed within the scheduled partition wall assembly with acoustical box pads, such as Lowr's or equivalent, applied at all locations. All unused knock-outs in outlet boxes are plugged with knock-out caps. Dimensions are provided for both single outlets and back-to-back outlet configurations.
SCHEDULED PARTITION DIMENSION FOR SINGLE OUTLETS DIMENSION FOR BACK TO BACK OUTLETS ELECTRICAL BOX NTS PROVIDE ACOUSTICAL BOX PADS, LOWR'S OR EQUIVALENT AT ALL LOCATIONS, TYP PLUG ALL UNUSED KNOCK- OUT IN OUTLET BOXES WITH KNOCK-OUT CAPS BOX PAD, TYP. DATA/TELEPHONE BOX ELECTRICAL BOX DATA/TELEPHONE BOX
