A three-quarter-inch tempered glass panel extends upward from a shoe element belonging to a Panelgrip dry glaze glass railing system. The shoe element is flanked by blocking as required and encased in a stone base with a scheduled floor assembly below at Level 1. A three-eighths-inch joint filled with backer rod and sealant is provided adjacent to the glass panel. Stone infill pieces run continuously along the opening on both sides of the base assembly.
LEVEL 1 100'-0" 6 2 1/8" 1 3/8" 1 1/2" 1 3/8" 2 1/8" 3/8" JOINT. FILL WITH BACKER ROD & SEALANT. STONE BASE BLOCKING AS REQUIRED SHOE ELEMENT OF PANELGRIP DRY GLAZE GLASS RAILING SYSTEM. INSTALL PER MANUFACTURER'S DIRECTIONS SCHEDULED FLOOR STONE INFILL PEICE. RUN CONTINUOUS ALONG OPENING. TYPICAL OF BOTH SIDES 3/4" TEMPERED GLASS PANEL. TYPICAL OF 3 SECTIONS DOOR/WINDOW CASING; SCALE DRAWN BY CHECKED BY PROJECT NUMBER FILE DATE SECTION DETAILS 06-21-13
