An exterior wall penetration houses a twenty-four gauge minimum galvanized steel conductor functioning as an overflow scupper sized per the applicable plumbing code. The roof assembly receives a roof membrane installed per the roofing manufacturer's recommendations, extending up and through the scupper opening. Approved sealant is applied at the exterior frame joints. The scupper maintains a one-inch minimum extension, and a four-inch dam height is established above the level of water flow at the drain head.
ROOF ASSEMBLY ROOF MEMBRANE, INSTALL PER ROOFING MANUFACTURER'S RECOMMENDATIONS EXTERIOR WALL, SEE FLOOR PLANS 24 GA. MIN. GALVANIZED STEEL CONDUCTOR APPROVED SEALANT (*) OVERFLOW SCUPPER TO BE SIZED PER APPLICABLE PLUMBING CODE 1" MIN 4" (*) DAM HEIGHT ABOVE LEVEL OF WATER FLOW AT DRAIN HEAD
