The assembly features a hose reel mounted to a wall or structural column at four feet above the finish floor with a dedicated support bracket. A water supply line from the high-pressure washer connects to the reel and includes a shut-off valve and water shock absorber. A galvanized rigid conduit routes control wiring down to push-button controls positioned four feet above the floor. A wash wand rests in an angled wand scabbard mounted at forty-five degrees and one foot above the finish floor.
GALVANIZED RIGID CONDUIT (GRC) FOR CONTROL WIRE TO HIGH PRESSURE WASHER WATER SUPPLY FROM HIGH PRESSURE WASHER; PROVIDE SHOCK ABSORBER ON WATER SUPPLY; REFERENCE EQUIPMENT WAND SCABBARD FINISH FLOOR WASH WAND PUSH BUTTON CONTROLS 4' - 0" 1' - 0" SHUT-OFF VALVE 4' - 0" 3' - 0" 1' - 0" HOSE REEL HOSE REEL SUPPORT MOUNTED TO WALL/COLUMN PIPE SUPPORT ATTACHED TO WALL OR STRUCTURE (TYP) 45°
