A three-inch expansion joint bridges adjacent data hall ceiling assemblies specified per schedule. Metal framing members connect to the expansion joint profiles using mechanical fasteners. Exposed components feature a white finish.
3" DATA HALL CEILING AS SCHEDULED DATA HALL CEILING AS SCHEDULED FINISH TO BE WHITE
