A-4HHP2 — Penetration at Sound and Smoke Partition

Architectural · A-4HHP2

Penetration at Sound and Smoke Partition

Elements

Partitions Roof / Floor Openings

About this detail

Piping, conduit, duct, or other penetrations pass through a framed partition with an opening oversized by a maximum of one-half inch. The annular space around the penetration is sealed airtight on both sides using backer rod and a white, non-hardening acoustic sealant typical at each side of the wall assembly.

SEAL JOINT AIRTIGHT ON BOTH SIDES WITH BACKER-ROD AND WHITE, NON- HARDENING, ACOUSTIC SEALANT, TYP. PIPING, CONDUIT DUCT OR OTHER PENETRATION 1/2" MAX OPENING TO BE OVERSIZED 1/2" MAX 1/2" MAX
