Typical Drip Tubing

About this detail

Irrigation zone control and drip tubing assembly featuring a six-inch drip box resting on a three-inch thick layer of washed gravel over a polyvinyl chloride lateral line connected via a three-quarter-inch schedule eighty nipple and three-quarter-inch female pipe thread by one-half-inch drip tubing adapter. One-half-inch drip tubing connects to compression tees and compression fittings. Plant landscaping layout includes one-quarter-inch distribution tubing with a maximum length of forty-eight inches, transfer barb tees for double emitters, and tube stakes with emitters or caps placed three-quarters between the trunk and outer dripline. Drip tubing is staked at each tee, ell, coupler, emitter, transfer, and at six-foot maximum on-center spacing.
