The suspended ceiling grid is supported by 12-gauge hanger wires installed vertically or at a maximum slope of one in six, positioned a maximum of eight inches from the wall. A tee end retaining clip secures the grid tee to the wall angle, which is attached directly to the wall. All grid members are screw-attached to the retaining clip. Minimum clearances include three-eighths of an inch above and seven-eighths of an inch at the wall angle bearing.
12 GA. HANGER WIRE; INSTALL EITHER SLOPED 1:6 MAX OR VERTICALLY. 7/8" MIN. 8" MAX. 3/8" MIN. A.1 DETAIL @ TWO ADJACENT WALLS WITH GRID ATTACHED TO WALL ANGLE TEE END RETAINING CLIP SCREW ATTACH ALL GRID TO CLIP 1 IN 6 MAX. WALL ANGLE; ATTACH TO WALL.
