A metallic oxide waterproofing layer with a protective coating is applied to the exterior face of the structural concrete wall. Waterproofing mortar seals the joint beneath the door sill and sill guard assembly. A partition system sits atop the concrete slab adjacent to the door frame.
METALLIC OXIDE WATERPROOFING W/PROTECTIVE COATING LINE OF CAR STRUCTURAL CONCRETE. REFER TO STRUCTURAL DRAWINGS FOR ADDITIONAL INFORMATION. WATERPROOFING MORTAR DOOR SILL LINE OF SILL GUARD 1 1/4" PARTITION SYSTEM 5"
