A 3/16 inch aluminum plate cladding panel is mounted to the exterior via an aluminum plate attachment system and required blocking. A waterstop and below grade waterproofing protect the concrete foundation wall, supplemented by a drainage mat behind the concrete paving. Stainless steel flashing integrates with the waterproofing system at the base transition. Interior finishes are coordinated per interior drawings.
EXTERIOR EXHIBIT 2 370'-6" CONC PAVING, SLD BELOW GRADE WATERPROOFING STAINLESS FLASHING BLOCKING AS REQ, SEE INT DWGS INT FINISH, SEE INT DWGS DRAIN MAT FO AL PL DIM PT 4" WATERSTOP EOS DIM PT 1" 3/16" ALUM PLATE, SEE FOR ADDITIONAL NOTES ALUM PLATE ATTACHMENT SYSTEM
