Unfaced acoustic fiberglass insulation board is adhered directly to the underside of the concrete slab using manufacturer-recommended adhesive. The concrete slab above is detailed per the structural drawings.
UNFACED ACOUSTIC FIBERGLASS INSULATION BOARD. ADHERE TO SLAB WITH MANUFACTURER RECOMMENDED ADHESIVE. CONCRETE SLAB. REFER TO STRUCTURE DWGS. ACOUSTIC FIBERGLASS BOARD, TYPICAL
