A built-up metal header spans a wall opening supported by back-to-back vertical studs at the jambs. The header track is connected to studs with number eight screws at twelve inches on center. Back-to-back jamb studs are also fastened together with number eight screws at twelve inches on center. A continuous top track connects to the floor slab above using zero point one eight zero inch power-driven shot pins at sixteen inches on center. A closure stud is provided at the opening jamb as specified in the schedule.
SEE CHART SCHED. SCHED. CHART SEE CONCRETE SLAB #8 SCREWS @ 12" O.C. #8 SCREWS @12" O.C. CLOSURE STUD OPENING JAMB REQ'D FOR SEE SCHEDULE BUILT-UP HEADER W/ #8 SCREWS TRACK ATTACH TRACK TO STUD AT EACH FLANGE TOP TRACK BACK TO BACK STUDS W/ #8 SCREWS @ 12" O.C. SEE SECTIONS 3-#8 SCREWS SCHEDULE AND STUD METAL STUD WALL SIZE & SPACING CONT. TRACK W/ .180" POWER DRIVEN SHOT PINS AT 16" O.C. U.N.O. AT SECTIONS (ESR-1799) OR APPROVED EQUAL OPENING
