A four-inch by ten-inch light fitting housing is provided by the curtain wall contractor, featuring finishes that match the curtain wall mullion. All wiring and electrical components are coordinated and concealed within the curtain wall system.
4" 10" LIGHT FITTING HOUSING BY CURTAINWALLER. FINISHES TO MATCH CURTAIN WALL MULLION. WIRING/ELECTRICAL TO BE COORDINATED AND TO BE CONCEALED IN CURTAIN WALL SYSTEM.
