Pre-finished aluminum composite metal panels mount over metal stud framing with an intervening layer of high-temperature water-resistive barrier over glass-mat gypsum sheathing board. The horizontal joint features a three-quarter-inch reveal centered between panel modules. Joint alignment is referenced to the center of the panel joint and reveal.
PRE-FINISHED ALUMINUM COMPOSITE METAL PANEL METAL STUD FRAMING HIGH TEMPERATURE WRB OVER GLASS-MAT GYPSUM SHEATHING BOARD PANEL MODULE PANEL MODULE CENTER OF PANEL JOINT CENTER OF REVEAL SEE WALL SECTIONS 3/4"
