Nestables sidelaps are positioned at the top in an inverted position and fastened with number 12-14 by 3/4-inch Teks 1 screws spaced at 12 inches on center. The steel deck, sized per plan, utilizes a Teks screw 36/4 pattern across the flutes. Two rows of boundary screws are provided all around the openings.
