An HVAC duct penetrates an acoustical partition framed with metal tracks and gypsum board layers enclosing batt insulation. Continuous fire-rated acoustical sealant is applied all around both sides of the penetration with a typical one-half-inch gap. Any gap larger than one-half inch requires a gypsum board patch lapped a minimum of two inches, secured with screws, and sealed with acoustical sealant. Ceilings are installed where indicated on drawings.
CLG WHERE OCCURS BATTS INSULATION TYP. 1/2" DUCT PENETRATIONS PER MECHANICAL DRAWINGS CONT. FIRE RATED SEALANT ALL AROUND BOTH SIDES PER MECHANICAL METAL TRACK PENETRATIONS OF ACOUSTICAL PARTITIONS BY DUCTWORK SHALL BE ACOUSTICALLY SEALED AS SHOWN. ANY GAP LARGER THAN 1/2" SHALL BE COVERED WITH GYPSUM BOARD, LAPPED A MINIMUM OF 2" AND SCREWED BEFORE USING ACOUSTICAL SEALANT.
