An exterior wall panel with a PVC finish meets an interior partition positioned according to plan. A minimum three-inch thick layer of foil-faced insulation fills the bridge cavity above a structural deck plate. The deck plate is supported by a steel beam below.
EXT WALL PANEL, PVC INT PARTITION PER PLAN 13 FIP INSUL, MIN 3" THK DECK PLATE PER STRUCTURAL
