A three-eighths-inch thick galvanized steel angle forms the edge containment for the roof grate system and ties back into the building column. Stainless steel type three hundred sixteen mill finish fasteners with type RI-eighteen hundred inserts attach the grate to the steel angle per pedestal manufacturer recommendations. Roof pavers are installed adjacent to the assembly. All exposed metals are galvanized, and the overall mechanical roof screen extends to one hundred fourteen feet two and one-half inches.
ROOF 96'-0" T.O. PARAPET 100'-0" T.O. MECHANICAL ROOF SCREEN 114'-2 1/2" PENTHOUSE ROOF 109'-0" NOTE: ALL EXPOSED METALS ARE GALVANIZED A8.43 01 3/8" THICK GALV STL ANGLE EDGE, STEEL ANGLE CONTAINMENT MUST FULLY CONTAIN GRATE SYSTEM AND MUST TIE BACK INTO BUILDING OR BUILDING COLUMN PAVERS AT THE ROOF. STAINLESS STEEL, TYPE 316 FASTENER, MILL FINISH, TYPE RI-1800 INSERT. ATTACH GRATE TO STEEL ANGLE. INSTALL PER PEDESTAL MFR RECOMMENDATIONS A8.43 2
