Suspended gypsum board ceiling framing featuring carrying channels spaced at forty-eight inches on center maximum with hanger wires positioned within six inches of channel ends. Furring channels run perpendicular beneath the carrying channels spaced at twenty-four inches on center maximum. Gypsum board panels are secured to the underside of the furring channels.
6" OF ENDS OF CARRYING CHANNELS 48" O.C. MAX. AND WITHIN SPACING 24" O.C. MAX
