A one-and-a-half-inch outside diameter seamless tubing conforming to ASTM A519 serves as the stair handrail, finished with high-gloss enamel in a color selected by the architect. Rail supports are spaced at six feet on center using Julius Blum number two-seventy-five supports with a six-twenty-six finish. An anchor bolt secures the bracket directly into the concrete shear wall, positioned two feet ten inches to the nosing of the treads.
1-1/2" O.D. SEAMLESS TUBING (ASTMA519) W/ HIGH GLOSS ENALMEL FINISH COLOR BY ARCH. "JULIUS BLUM #275 W/ 626 FINISH" RAIL SUPPORTS @ 6'-0" O.C. ANCHOR BOLT 2'-10" TO NOSING OF TREADS CONCRETE SHEAR WALL - PER STRUCTURAL DRAWINGS STRUCTURAL PER
