A-3ZX3A — Slab Edge @ Stair Shaft

Architectural · A-3ZX3A

Slab Edge @ Stair Shaft

Scale: 3" = 1'-0"
Units: imperial
Sheet: A-802
Discipline: Architectural

Materials

Cold-formed Steel Composite Concrete Metal (misc.)Steel

Elements

Decks Expansion / Control Joints Floors / Slabs Stairs Walls

Connections

Deck Attachment Shear Stud / Composite

Text on the drawing

CONTROL JOINT ON EACH LEVEL AND 30'-0" OC HORIZONTALLY DEEP LEG MTL TRACK, MECHANICALLY FASTEN 24" OC MAX CONCRETE DECK TRACK, MECHANICALLY FASTEN 24" OC MAX RATED WALL AS SCHEDULED COMPOSITE DECK EDGE FORM FIRE STOP SEALANT 7/8" HAT CHANNEL AS REQUIRED
