Metal panels meet at an interior 90-degree corner over exterior wall framing and continuous batt insulation. The assembly includes exterior metal wall panels backed by continuous insulation layers and framing tracks. A joint sealant and trim piece seal the internal corner junction between the intersecting wall planes.
