This seismic bracing detail connects a splayed seismic bracing wire to the overhead structure using a minimum 5/16-inch diameter drill-in expansion anchor. A steel strap measuring 1 inch wide by 2 inches long and 12 gauge minimum is bent to align with the wire. The bracing wire is secured with four tight turns in 1 1/2 inches at a maximum 45-degree angle. The entire suspended ceiling bracing assembly complies with DSA IR 25-2, ASTM C635, and ASTM C636.
NOTE: SUSPENDED CEILING BRACING ASSEMBLY PER DSA IR 25-2. 2022, ASTM C635, AND ASTM C636 STRUCTURE ABOVE 5/16" DIAMETER (MINIMUM) DRILL- IN EXPANSION ANCHOR STEEL STRAP 1" WIDE X 2" LONG X 12 GA. (MINIMUM), BEND TO ALIGN WITH WIRE SPLAYED SEISMIC BRACING WIRE WITH 4 TIGHT TURNS IN 1 1/2" (1 1/2") NTS (5/8" MAX.) (45° MAX.) B: SPLAY BRACING WIRE ATTACHMENT
