Multiple cables or conduits pass through a sleeve installed within a partition wall sized per plan. A one-eighth inch typical clearance is maintained around the assembly to ensure conduits or pipes do not contact the wall directly. The annular space between the sleeve and cables is packed with closed cell polyurethane foam or fire-rated silicone foam.
1/8" CLEAR TYP., (CONDUIT OR PIPE SHALL NOT CONTACT WALL) MULTIPLE CONDUIT CLOSED CELL POLYURETHANE FOAM OR FIRE RATED SILICONE FOAM, TYP. SLEEVE WITH MULTIPLE CABLES MULTIPLE CONDUIT PARTITION PER PLAN
