This wall header assembly features exterior metal siding installed over an exterior gypsum sheathing and a liquid-applied weather barrier with taped joints. A pre-finished metal drip edge terminates the exterior cladding above the window head condition. The interior side is finished with 5/8-inch gypsum board over a framed wall as scheduled.
METAL SIDING - SEE EXTERIOR ELEVATIONS PRE-FINISHED METAL DRIP EDGE LIQUID-APPLIED WEATHER BARRIER SHEATHING JOINT TAPE EXTERIOR GYPSUM SHEATHING - SEE STRUCTURAL 5/8" GYP. BOARD WALL AS SCHEDULED
