An interior architectural assembly at the intersection of a bulkhead with a wall partition, maintaining an eight-inch clear dimension. The construction features metal framing studs faced with gypsum wallboard layers and filled with thermal batt insulation. A coordinate note references adjacent casework located on sheet AE4-56.
4" 4" 8" Clear 5 6 7 8 9 E6 AE4-32 23 5 24 25 26 AE5-52 B3 See AE4-56 for Casework
