A heavy structural steel base plate measuring two and one-half inches thick is equipped with a weak axis gusset plate welded per manufacturer specifications. The layout features two-inch typical corner radii and machine scribe lines on the top surface centered on grid lines at one-sixteenth inch wide by one-thirty-second inch deep. Anchor bolt holes are positioned symmetrically around the column profile with specific offset dimensions and minimum clearances. The bottom surface of the base plate is designated with a TSC finish marker.
Z 9 1' - 0 1/2" 1' - 0 1/2" 1' - 3" 1' - 3" MIN 1/2" R 2" TYP BASE PLATE, 2 1/2" THICK 4 1/2" 4 1/2" MACHINE SCRIBE LINES ON TOP OF BASE PLATE, CENTERED ON GRID LINES, 1/16" WIDE x 1/32" DEEP PER GUSSET MFR ( 1' - 7" ) TSC BOTTOM SURFACE OF BASE PL
