Floor finish transitions at a scheduled door threshold connect different flooring materials across the centerline of the door and trim. Condition A shows matching floor finish material on both sides of the opening over a concrete slab. Condition B details a transition strip and carpet reducer strip matching the rubber base between carpet tile and resilient floor material. Condition C shows a transition strip reducer matching the rubber base at the edge of a resilient floor and concrete slab.
TRANSITION STRIP CPT REDUCER STRIP TO MATCH RUBBER BASE CONCRETE SLAB SCHEDULED DOOR DOOR AND TRIM A C TRANSITION STRIP CPT REDUCER STRIP TO MATCH RUBBER BASE CARPET/CARPET TILE RESILIENT FLOOR MATERIAL SCHEDULED DOOR DOOR AND TRIM B FLOOR FINISH MATERIAL, SAME ON BOTH SIDES OF OPENING SCHEDULED DOOR DOOR AND TRIM 0" 0" 0"
