An exterior stair upper landing assembly connects precast treads and risers to a structural steel stringer supported by painted steel angle brackets welded to the stringer and bolted to the treads. The stair framing meets a concrete topping slab over a metal deck and wide-flange beam, adjoining a brick veneer wall assembly with a continuous stainless steel bar ledge and high-performance coated steel angles. An extruded aluminum guardrail with vertical pickets spaced at three and three-quarter inches on center is paired with a painted steel handrail finished with a three-part PVDF coating. A concrete curb with metal flashing is positioned adjacent to the topping slab.
LEVEL P3 RR 188'-2" STEEL STRINGER / STAIR SUPPORT- SEE STRUCTURAL PTD WITH HIGH PERFORMANCE COATING STEEL ANGLE BRACKETS WELDED TO THE STRINGER AND BOLTED TO THE PRECAST TREAD PRECAST TREAD- RISER STAIR TYP. 3 3/4" PTD. STEEL HANDDRAIL EXTRUDED ALUMINUM PICKETS PTD W/ 3 PART PVDF HSS BEAM PTD WITH HIGH PERFORMANCE COATING CONCRETE TOPPING SLAB, PATTERN PER LANDSCAPE CONCRETE CURB WITH METAL FLASHING BEYOND EXTRUDED ALUMINUM GUARDRAIL, BEYOND CONT. STAINLESS STEEL BAR LEDGE BEYOND CONT. HIGH PERFORMANCE COATED STEEL ANGLES, BEYOND 11 A8.40 10 A8.40 _____________________ A8.40 7 Sim BRICK VENEER WALL ASSEMBLY. PLATE STEEL PTD WITH HIGH PERFORMANCE COATING
