A four-inch concrete wall panel bears on a reinforced concrete grade beam with bituminous waterproofing applied typically at all foundations one foot below the finish floor. A one-inch maximum expansion board with a removable cap and continuous sealant separates the wall panel from the concrete floor slab. The slab bears on a ten-mil vapor barrier over properly compacted fill.
4" CONC. WALL PANEL GRADE BITUMINOUS WATERPROOFING (TYP. @ ALL FOUNDATIONS 1'-0" BELOW FINISH FLOOR FOUNDATION 1" (MAX.) EXPANSION BOARD W/ REMOVABLE CAP AND CONT. SEALANT CONC. FLOOR SLAB PER FOUNDATION DWGS. REINF. CONC. GRADE BEAM PER FOUNDATION DWGS. 10 MIL VAPOR BARRIER ON PROPERLY COMPACTED FILL PER FOUNDATION DWGS.
