A plastic laminate countertop is supported by a built-up core featuring an exposed edge condition. A dimension of one and one-half inches is maintained to the dimension point, with an additional quarter-inch offset. A cabinet door or drawer is positioned below where applicable, aligned according to the indicated dimension points.
AT WOOD VENEER OR PLASTIC LAMINATE WITH EXPOSED EDGE CABINET DOOR/DRAWER WHERE OCCURS DIM PT DIM PT EXPOSED CORE 1 1/2" 1/4" PLASTIC LAMINATE COUNTERTOP
